| Model | FX801V |
| Engine type | Air-cooled, 4-stroke, Vertical shaft, OHV |
| Valve's form | OHV |
| Displacement | 852 cm3 |
| Bore x stroke | 84.5 x 76 mm |
| Max. power | 18.9 kW (25.3 hp) / 3600 rpm |
| Max. torque | 63.0 Nm (46.4ft.lbs) / 2200 rpm |
| Fuel tank capacity | - L |
| Oil capacity | 2.4 L |
| Dimensions | 488 x 472 x 626 (L*W*H mm) |
| Dry Weight | 56.4 kg |
